Main advantages:

  • Folding aluminum construction;
  • The dock shelter topsheet can be either single or double — to provide better contact with the vehicle body;
  • Built-in springs allow the front folding frame to follow the vehicle body, preventing damage to the structure (in the case of incorrect vehicle parking);
  • White reflective stripes located in front of the vertical sheets provide an accurate vehicle parking.


Dimensions / Features
Width, mm 3000 / 3200 / 3400
Height, mm 3000 / 3200 / 3400 / 4400
Upper sheet
• Standard Single
• Upper request Double
Colour of profiles White aluminum (RAL 9006)
Front Sheet - PVC
Lengthwise tear resistance more than 550 n
Widthwise tear resistance more than 900 n
Ultimate tensile strength 250 n/mm
Metal friction coefficient 0,3
PVC friction coefficient 0,4
Thickness 3 mm
Operating temperature from -35 to 90 °С
Side fabric - PVC
Tear resistance 250 n
Thickness 0,5 mm
Operating temperature from -35 to 70 °С
Aluminum frame
Rear frame profiles 50×44 mm
Front frame profiles 45×44 mm
Brace 50x25x2,5 mm
Front clamping bar 34×4,8 mm
  Standard Option
Dock shelter depth 600 mm 900 mm
Upper sheet Single Double
Profile colour White aluminum (RAL 9006) Other upon request
Seal - Small / Large corner cushion in bottom part

Construct and size

  • 1. Upper front sheet
  • 2. Side front sheet
  • 3. Brace
  • 4. Spring
  • 5. Integral stocking with water flow system
  • 6. White reflective
  • 7. Harness rubber

Dock Shelters of D.SH-RT series, consist of front and rear frames made of aluminum profiles which are connected to each other by braces. At the connection a cable is installed with a spring to provide the necessary elasticity of the structure. Front and upper side sheets are made of PVC and reinforced with two layers of polyester. The top sheet has special cuts for a tighter fit to the car body. Vertical front sheets have white reflective stripes, which ease the car parking. Side and top “sleeves” are made of a material which has a layer of synthetic reinforcement.
